Anchor Penta 6A Uno Mini SP C-Type MCB,98236, Breaking Capacity: 3 kA, (Pack of 12)

The Anchor Penta Uno 6A Single Pole C Curve White Mini MCB, model 98236, available in a pack of 12, is designed to protect electrical circuits from overloads and short circuits. It features a white mini modular design with a breaking capacity of 3 kA, suitable for single-pole installations with a rated voltage of 240V AC and frequency of 50 Hz.

Key Specifications:

• Poles: Single Pole (1P)

• Rated Current: 6 Amperes

• Curve Type: C Curve (thermal-magnetic tripping for moderate inrush currents)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Mounting: Snap-fit/screw mounted (on board)

• Protection Class: IP20 (finger-proof terminals)

• Terminal Capacity: Supports cables up to 35 mm²

• Standards: IS/IEC 60898-1 compliant

• Color: White

• Manufacturer: Panasonic Life Solutions India Pvt. Ltd.

Features:

• Mid-trip indication for clear fault identification

• Trip-free mechanism to prevent manual override during fault conditions

• Low wattage loss design for energy efficiency

• Compact mini modular form factor for easy installation and maintenance

This MCB offers reliable and efficient circuit protection suitable for various residential and commercial electrical applications.
