Anchor Penta 25A Uno Mini DP C-Type MCB,98250, Breaking Capacity: 3 kA (Pack of 12)

The Anchor Penta 25A Uno Mini Double Pole C-Type MCB, model 98250, provides reliable circuit protection with a breaking capacity of 3 kA (3000A). It is rated for 25 Amperes, operates at 240V AC with 50 Hz frequency, and features a C Curve trip characteristic suitable for moderate inrush currents. This MCB is made from flame-retardant materials, supports double pole configuration, and offers modular snap-fit or flush screw mounting options. It complies with IS/IEC 60898-1 standards for safety and performance.

Key Specifications:

• Rated Current: 25 Amperes

• Poles: Double Pole (2P)

• Curve Type: C Curve (thermal-magnetic trip)

• Rated Voltage: 240 V AC

• Frequency: 50 Hz

• Breaking Capacity: 3 kA (3000A)

• Material: Flame-retardant polycarbonate housing

• Installation: Modular snap-fit or flush screw mounted

• Certification: IS/IEC 60898-1 compliant

• Color: White

• Packaging: Pack of 12

Features:

• Efficient protection against overload and short circuits

• Mid-trip indication for easy fault detection

• Compact design for easy installation and sustainability

This MCB is suitable for residential, commercial, and light industrial circuits requiring dependable and safe protection at a 25A rating.
