Anchor Penta 10A Uno Mini DP C-Type MCB,98247, Breaking Capacity: 3 kA (Pack of 12)

The Anchor Penta 10A Uno Mini Double Pole C-Type MCB, model 98247, features a breaking capacity of 3 kA (3000A). It is designed for reliable electrical protection in both residential and commercial settings. This MCB operates at 240V AC with a frequency of 50Hz, suitable for low-load applications such as lighting and small appliances. Made with high-quality, flame-retardant materials, it offers safety with a compact, modular design that supports snap-fit or flush screw mounting. It is compatible with applications requiring single or double pole configurations and aligns with international standards for safety and performance.

Key Features:

• Rated current: 10 Amperes

• Pole configuration: Double Pole (DP)

• Trip characteristic: C Curve

• Breaking capacity: 3 kA (3000A)

• Rated voltage: 240V AC

• Frequency: 50Hz

• Material: High-quality, flame-retardant polycarbonate

• Installation: Modular snap-fit or flushmount

• Certification: IS/IEC 60898-1 compliant

Applications:

This MCB is ideal for protecting residential, commercial, and industrial circuits against overloads and short circuits. Its high short circuit breaking capacity makes it particularly suitable for heavy appliances or circuits with moderate inrush currents.
